| Camera |
| Image Sensor |
1/2.8″ CMOS |
| Max. Resolution |
3840 (H) Ć 2160 (V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 sā1/100,000 s |
| Min. Illumination |
0.004 lux@F1.0 (Color, 30 IRE)
0.0004 lux@F1.0 (B/W, 30 IRE)
0 lux (illuminator on) |
| S/N Ratio |
ļ¹„ 56 dB |
| Illumination Distance |
30 m (98.43 ft) (IR)
30 m (98.43 ft) (warm light) |
| Illuminator On/Off Control |
Auto; manual |
| Illuminator Number |
1 (IR LED)
1 (warm light) |
| Pan/Tilt/Rotation Range |
Pan: 0Ā°ā360Ā°
Tilt: 0Ā°ā78Ā°
Rotation: 0Ā°ā360Ā° |
| Lens |
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Field of View |
2.8 mm: Horizontal: 106Ā°Ć Vertical: 55Ā°Ć Diagonal: 125Ā°
3.6 mm: Horizontal: 85Ā°Ć Vertical: 45Ā°Ć Diagonal: 100Ā° |
| Iris Type |
Fixed |
| Close Focus Distance |
2.8 mm: 2.0 m (6.56 ft)
3.6 mm: 2.8 m (6.23 ft) |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
91.0 m (298.56 ft) |
36.4 m
( 119.42 ft) |
18.2 m
(59.71 ft) |
9.1 m
(29.86 ft) |
| 3.6 mm |
107.6 m (353.02 ft) |
43.0 m
( 141.08 ft) |
21.5 m
(70.54 ft) |
10.8 m
(35.43 ft) |
| Professional, intelligent |
| IVS (Perimeter Protection) |
Tripwire; intrusion (Support the classification and accurate detection of vehicle and human) |
| SMD 3.0 |
Less false alarm, longer detection distance |
| Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec |
Smart H.265+; Smart H.264+ |
| AI Coding |
AI H.265; AI H.264 |
| Video Frame Rate |
Main stream: 3840 Ć 2160@(1 fpsā30 fps)
Sub stream: 704 Ć 576@(1 fpsā25 fps)/704 Ć 480@(1 fpsā30 fps)
Third stream: 1920 Ć 1080@(1 fpsā30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability |
3 streams |
| Resolution |
8M (3840 Ć 2160); 6M (3072 Ć 2048); 5M (3072 Ć 1728/2592 Ć 1944); 4M (2688 Ć 1520); 3M (2048 Ć 1536/2304 Ć 1296); 1080p (1920 Ć 1080); 1.3M (1280 Ć 960); 720p (1280 Ć 720); D1 (704 Ć 576/704 Ć 480); VGA (640 Ć 480); CIF (352 Ć 288/352 Ć 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 3 kbpsā20480 kbps
H.265: 3 kbpsā20480 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation |
Yes |
| White Balance |
Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control |
Auto; manual |
| Noise Reduction |
3D NR |
| Motion Detection |
OFF/ON (4 areas) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Defog |
Yes |
| Image Rotation |
0Ā°/90Ā°/180Ā°/270Ā° (Support 90Ā°/270Ā° with 2688 Ć 1520 resolution and lower) |
| Mirror |
Yes |
| Privacy Masking |
8 areas |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
PCM; G.711a; G.711Mu; G.726; G.723 |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception |
| Network |
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Cyber Security |
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade |
| Protocol |
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
| User/Host |
20 (Total bandwidth: 72 M) |
| Storage |
FTP; SFTP; Micro SD card (Support max. 256 G); NAS |
| Browser |
IE: IE8/9/11
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Phone |
iOS; Android |
| Certification |
| Certification |
CE-LVD: EN 62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL:UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port |
| Audio Input |
1 channel (RCA port) |
| Audio Output |
1 channel (RCA port) |
| Alarm Input |
1 channel in: 5 mA 3Vā5 VDC |
| Alarm Output |
1 channel out: 300 mA 12 VDC |
| Power |
| Power Supply |
12 VDC/PoE (802.3af) |
| Power Consumption |
Basic: 2.9 W (12 VDC); 5.0 W (PoE)
Max. (H.265+main stream/IR intensity+warm light on): 7.8 WĀ (12 VDC) 9.6 W (PoE) |
| Environment |
| Operating Conditions |
ā40 Ā°C to +60 Ā°C (ā40 Ā°F to +140 Ā°F)/Less than 95% RH |
| Storage Conditions |
ā40 Ā°C to +60 Ā°C (ā40 Ā°F to +140 Ā°F) |
| Protection Grade |
IP67 |
| Structure |
| Casing |
Metal |
| Dimensions |
110.9 mm Ć Ī¦122.0 mm (4.4″ Ć Ī¦4.8″) |
| Net Weight |
745 g (163.1 lb) |
| Gross Weight |
915 g (200.6 lb) |
