| Camera |
| Image Sensor |
1/2.7ā4Megapixel progressive CMOS |
| Max. Resolution |
2688 (H) Ć1520 (V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 sā1/100, 000 s |
| Min. Illumination |
0.003 Lux @ F1.0 |
| S/N Ratio |
> 56 dB |
| Illumination Distance |
30 m (98.4 ft) (Warm light) |
| Illuminator On/Off Control |
Auto/Manual |
| Illuminator Number |
2 (warm LED) |
| Pan/Tilt/Rotation Range |
Horizontal: 0Ā°ā360Ā°; vertical: 0Ā°ā78Ā°; rotation: 0Ā°ā360Ā° |
| Lens |
| Lens Type |
Fixed-focal |
| Mount Type |
M12 |
| Focal Length |
2.8 mm; 3.6 mm |
| Max. Aperture |
F1.0 |
| Field of View |
2.8 mm: Horizontal 103Ā° Ć vertical 53Ā° Ć diagonal 122Ā°
3.6 mm: Horizontal 80Ā° Ć vertical 43Ā° Ć diagonal 95Ā° |
| Iris Type |
Fixed |
| Close Focus Distance |
2.8 mm: 1.2 m (3.9 ft)
3.6 mm: 2.4 m (7.9 ft) |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8mm |
38.6 m
(126.6 ft) |
15.4 m
(50.5 ft) |
7.7 m
(25.3 ft) |
3.9 m
(12.8 ft) |
| 3.6mm |
80.0 m
(262.5 ft) |
32.0 m
(105.0 ft) |
16.0 m
(52.5 ft) |
8.0 m
(26.3 ft) |
| Professional, Intelligent |
| Perimeter Protection |
Tripwire, intrusion (Recognition of vehicle and people) |
| Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video |
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG(only supported by the sub stream) |
| Smart Codec |
Smart H.265+/ Smart H.264+ |
| Video Frame Rate |
Main stream (2688 Ć 1520 @ 1ā25/30 fps)
sub stream (704 Ć 576 @ 1ā25/704 Ć 480 @ 1-30 fps)
third stream (1280 Ć 720 @ 1ā25/30 fps) |
| Stream Capability |
3 streams |
| Resolution |
4M (2688 Ć 1520); 3M (2304 Ć 1296); 1080p (1920 Ć 1080); 1.3M (1280 Ć 960); 720p (1280 Ć 720); D1 (704 Ć 576/704 Ć 480); VGA (640 Ć 480); CIF (352 Ć 288/352 Ć 240) |
| Bit Rate Control |
CBR; VBR |
| Video Bit Rate |
H.264: 3 kbpsā8192 kbps
H.265: 3 kbpsā8192 kbps |
| Day/Night |
Color/B/W |
| BLC |
Yes |
| WDR |
120 dB |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Image Rotation |
0Ā°/90Ā°/180Ā°/270Ā° (Support 90Ā°/270Ā° with 1920 Ć 1080 resolution and lower.) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
| Audio |
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; G726; AAC |
| Alarm |
| Alarm Event |
No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; intensity change; tripwire; intrusion; SMD |
| Network |
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; SNMP |
| Interoperability |
ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec |
| Scene self-adaptation |
Yes |
| User/Host |
20 (Total bandwidth: 64M.) |
| Storage |
FTP; SFTP; Micro SD Card (support max. 256 G); Dahua Cloud; NAS |
| Browser |
IE: IE8; IE9; IE11
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Phone |
IOS; Android |
| Certification |
| Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Power |
| Power Supply |
12V DC/PoE |
| Power Consumption |
< 8.5W |
| Environment |
| Operating Conditions |
-40Ā°C to +60Ā°C (-40Ā°F to +140Ā°F)/ less than 95% |
| Storage Conditions |
-40Ā°C to +60Ā°C (-40Ā°F to +140Ā°F) |
| Protection Grade |
IP67 |
| Structure |
| Casing |
Inner core: Metal
Cover: Metal
Decoration ring: Plastic |
| Dimensions |
99.1 mm Ć Ī¦121.9 mm (3.9″ Ć Ī¦4.8″) |
| Net Weight |
480 g (1.05 lb) |
| Gross Weight |
660 g (1.45 lb) |
