| Camera |
| Image Sensor |
Panorama: 1/2.7″ CMOS; Detail: 1/2.8″ CMOS |
| Pixel |
Panorama: 8 MP; Detail: 4 MP |
| Max. Resolution |
Overview channel: 4096(H) Ć 1860(V); Overview channel: 2560(H) Ć 1440(V) |
| ROM |
Panorama: 4 GB; Detail: 4 GB |
| RAM |
Panorama: 2 GB; Detail: 1 GB |
| Electronic Shutter Speed |
1 sā1/30,000 s |
| Scanning System |
Progressive |
| Min. Illumination |
Panorama:
0.005 lux@F1.4 (Color, 30 IRE);
0.0005 lux@F1.4 (B/W, 30 IRE);
0 lux (illuminator on)
Detail:
0.005 lux@F1.6 (Color, 30 IRE);
0.0005 lux@F1.6 (B/W, 30 IRE);
0 lux (illuminator on) |
| Illumination Distance |
Panorama: 30 m (98.43 ft) (IR); 30 m (98.43 ft) (white light); Detail: 100 m (328.08 ft) (IR); 50 m (131.23 ft) (white light) |
| Illuminator On/Off Control |
Panorama:
Manual; Auto; Off
Detail:
Zoom Prio; Manual; Auto; Off |
| Illuminator Number |
Panorama: 2 (IR light); 2 (White light); Detail: 2 (IR light); 2 (Warm light) |
| Lens |
| Focal Length |
Panorama: 2.8 mm; Detail: 5 mmā125 mm |
| Max. Aperture |
Panorama: F1.4; Detail: F1.6-F3.6 |
| Field of View |
Panorama: H: 180Ā°; V: 86Ā°; Detail: H: 51.9Ā°ā3.0Ā°; V: 39.7Ā°ā2.2Ā°; D: 63.1Ā°ā3.7Ā° |
| Optical Zoom |
Panorama: NA;Detail: 25Ć |
| Focus Control |
Auto; manual; semi-auto |
| Close Focus Distance |
Panorama: 0.6 m (1.97 ft); Detail: 0.1 mā0.5 m (0.33″ā1.64″) |
| Iris Control |
Panorama: NA; Detail: Auto; manual; iris prio |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| Panorama: 2.8 mm; Detail: 5 mmā125 mm |
2,500 m
( 8202.10 ft) |
987.5 m
( 3239.83 ft) |
500 m
( 1640.42 ft) |
250 m
( 820.21 ft) |
| PTZ |
| Pan/Tilt Range |
Pan: 0Ā° to 360Ā° endless
Tilt: ā15Ā° to +90Ā°, auto flip 180Ā° |
| Manual Control Speed |
Pan: 0.1Ā°/sā180Ā°/s;
Tilt: 0.1Ā°/sā90Ā°/s |
| Preset Speed |
Pan: 0.1Ā°/sā180Ā°/s;
Tilt: 0.1Ā°/sā90Ā°/s |
| Preset |
300 |
| Tour |
8 (up to 32 presets per tour) |
| Pattern |
5 |
| Scan |
5 |
| Power-off Memory |
Yes |
| Idle Motion |
Preset;Pattern;Tour;Scan |
| Intelligence |
| IVS (Perimeter Protection) |
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human alarm classification; linkage tracking |
| SMD |
SMD 4.0 |
| Active Deterrence |
| Light Warning |
Red-Blue light warning;
Flash duration: 5 sā30 s;
Flash frequency: high, medium, low |
| Sound Warning |
Offers 11 sound alarm and 10 custom sound alarms can be imported.
Sound can be set from 0%ā100%.
Play times can be set from 1-10. |
| Video |
| Video Compression |
Smart H.265+;H.265;Smart H.264+;H.264B;H.264M;H.264H;MJPEG(Sub Stream 1) |
| Streaming Capability |
3 streams |
| Resolution |
Panorama: 8M (4096 Ć 1860); 2M (2048 Ć 928); 1080p (1920 Ć 1080); 720p (1280 Ć 720); 1024 Ć 448; D1 (704 Ć 576/704 Ć 480);VGA (640 Ć 480);CIF (352 Ć 288/352 Ć 240); Detail: 4M (2560 Ć 1440); 3M (2304 Ć 1296); 1080p (1920 Ć 1080); 1.3M (1280 Ć 960); 720p (1280 Ć 720); D1 (704 Ć 576/704 Ć 480);VGA (640 Ć 480); CIF (352 Ć 288/352 Ć 240) |
| Video Frame Rate |
Overview channel:
Main stream: 4096 Ć 1860 @(1ā25/30 fps)
Sub stream 1: 1024 Ć 448/D1/VGA/CIF @(1ā25/30 fps)
Sub stream 2: 2048 Ć 928/1080p/1.3M/720p @(1ā25/30 fps);
Detail channel:
Main stream: 4M/3M/1080p/1.3M/720p @(1ā25/30 fps)
Sub stream 1: D1/VGA/CIF @(1ā25/30 fps)
Sub stream 2: 1080p/1.3M/720p/ @(1ā25/30 fps) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
Panorama:
H264: 128 kbpsā16,384 kbps
H265: 51 kbpsā13,312 kbpsļ¼
Detail:
H264: 96 kbpsā16,384 kbps
H265: 38 kbpsā10,240 kbps; |
| Day/Night |
Panorama: Auto; Color; B/W; Electronic
Detail: Auto; Color; B/W; Electronic |
| BLC |
Yes |
| WDR |
Panorama: DWDR; Detail: 120 dB |
| HLC |
Yes |
| White Balance |
Panorama: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Detail: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control |
Panorama: Auto; manual; gain prio
Detail: Auto; manual; gain prio |
| Noise Reduction |
Panorama: 2D NR; 3D NR
Detail: Auto: 2D NR; 3D NR |
| Motion Detection |
Yes |
| Region of Interest (RoI) |
Yes |
| Image Stabilization |
Panorama: NA
Detail: Electronic Image Stabilization (EIS) |
| Defog |
Panorama: Electronic
Detail: Electronic |
| Digital Zoom |
Panorama: NA;
Detail: 16Ć |
| Image Rotation |
Panorama: NA
Detail: 180Ā° |
| S/N Ratio |
Panorama: ā„55 dB
Detail: ā„55 dB |
| Audio |
| Audio Compression |
PCM, G.711A, G.711Mu, G.726, MPEG2-Layer2, G.722.1, G.729 |
| Network |
| Network Port |
RJ-45 (100/1,000 Base-T) |
| Network Protocol |
HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;QoS;FTP;UPnP;ICMP;SNMP;IGMP;ARP;RTCP;RTP;PPPoE;RTMP;Bonjour;NFS |
| Interoperability |
ONVIF (Profile S & Profile G & Profile T);CGI;SDK;P2P |
| Streaming Method |
Unicast/Multicast |
| User/Host |
20 (total bandwidth: 64 M) |
| Storage |
Micro SD card (512 GB); FTP/SFTP; NAS |
| Browser |
web5.0:
IE 9 and later versions;
Chrome 41 and later versions;
Firefox 52 and later versions;
Safari 10 and later versions |
| Management Software |
DMSS;DSS Pro |
| Mobile Client |
iOS;Android |
| Certification |
| Certifications |
CE: EN55032/EN55024/EN50130-4 |
| Port |
| Audio Input |
1 channel (LINE IN, bare wire) |
| Audio Output |
1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)ļ¼ |
| Alarm Input |
2 (on-off value input: 0ā5 VDC) |
| Alarm Output |
1 channel |
| Alarm Linkage |
Capture; recording; send email; preset; tour; pattern; alarm digital output; audio; warning light |
| Alarm Event |
Motion/tampering detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power |
| Power Supply |
12 VDC, 3 A Ā± 10%;PoE (802.3at) |
| Power Consumption |
Basic: 14 W;
Max: 25 W (illuminator + heating glass + Siren and Light Active Deterrence + ICR + PTZ) |
| Environment |
| Operating Temperature |
ā40 Ā°C to +65 Ā°C (ā40 Ā°F to +149 Ā°F) |
| Operating Humidity |
ā¤95% |
| Protection |
IP66;TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Structure |
| Product Dimensions |
194.2 mm Ć 160 mm Ć 311 mm (7.65″ Ć 6.30″ Ć 12.24″) (L Ć W Ć H) |
| Net Weight |
3.1 kg (6.83 lb) |
| Gross Weight |
3.1 kg (6.83 lb) |
