| Image Processing |
| Illuminator |
6 IR illuminators (brightness adjustable) |
| Image Sensor |
1/1.8” CMOS |
| Image Resolution |
1920 Ć 1080 (OSD black strip excluded) |
| Video Resolution |
Main stream: 1080P (1920 Ć 1080) / 720P (1280 Ć 720)
Sub stream: 720P (1280 Ć 720) / D1 (704 Ć 576, 704 Ć 480) / CIF (352 Ć 288, 352 Ć 240) |
| Video Frame Rate |
PAL: Main stream (1280 Ć 960@25fps, 1280 Ć 720@25fps), sub stream: (1280 Ć 720@25fps, 704 Ć 576@25fps, 352 Ć 288@25fps)
NTSC: Main stream (1280 Ć 960@30fps, 1280 Ć 720@30fps), sub stream (1280 Ć 720@30fps, 704 Ć 408@30fps, 352 Ć 240@30fps) |
| Bit Rate |
H.264B: 20Kbpsā32768Kbps
H.264M: 20Kbpsā32768Kbps
H.264H: 20Kbpsā32768Kbps
H.265: 20Kbpsā32768Kbps
MJPEG: 59Kbpsā65536Kbps |
| Video Encoding |
H.264B/H.264M/H.264H/H.265/MJPEG |
| Image Encoding |
JPEG |
| Noise Reduction |
3DNR |
| White Balance |
Full auto; auto color temperature range; customized color temperature |
| Electronic Shutter |
1/50ā1/10000, auto or manual |
| Wide Dynamic Range |
96db |
| Edge Enhancement |
Yes |
| Exposure Mode |
Full auto; customized auto; customized |
| Iris |
Auto iris (W:1.3āT:2.3) |
| Function |
| Trigger Mode |
Video detection; I/O coil; video detection and I/O coil |
| Shutter |
Single shutter |
| Storage |
1 built-in TF card port. Kingston 16G, 32G and 64G; Dahua 16G, 32G and 64G; SanDisk 16G, 32G and 64G |
| Image Tampering Prevention |
Yes. Video/picture can be checked through watermark and verification |
| Max Illumination Distance |
25m (82.02ft) |
| Alarm Event |
Alarm in the case of no storage card, not enough storage space, storage card error, network disconnection, IP conflict, and illegal access |
| Security Mode |
Authorized username and password, MAC address binding, HTTPS encryption, IEEE 802.1x, and network access control |
| OSD Overlay |
Supports overlay of time, address (position of channel), lane (number/direction), plate (number and color), vehicle (speed, color, type) |
| ANR (Automatic Network Replenishment) |
Yes. Platform/FTP |
| Auto Register |
Yes |
| Intelligence |
| Vehicle Detection |
Vehicle capture rate ā„99% |
| Vehicle Recognition |
Supports recognizing vehicle type, vehicle logo, vehicle color, license plate, and vehicle without plate. Vehicle recognition rate ā„90% |
| Video Metadata |
Yes |
| Intelligent Track Frame |
Intelligent frame display. Supports displaying vehicle plate and vehicle path |
| Ports |
| Lens |
Module lens |
| Analog Output |
1 |
| Ethernet Port |
1 100/1000M Ethernet port (RJ45) |
| RS-485 port |
1 |
| I/O Port |
2, optocoupler input (switch quantity) |
| Alarm Input |
1, optocoupler input (switch quantity) |
| Alarm Output |
2-channel relay output, connecting to devices such as barrier |
| Audio Input |
1-channel RCA port |
| Audio Output |
1-channel RCA port |
| Power Output |
12V DCĀ±10% voltage output, ā¤1A current output |
| General |
| Power Supply |
12V DC, 24V AC, PoE |
| Power Consumption |
< 20W |
| Working Temperature |
ā30Ā°C to +65Ā°C (ā22Ā°F to +149 Ā°F) |
| Working Humidity |
10%ā90% (no condensation) |
| Housing |
Metal and plastic |
| Protection Grade |
IP67 |
| Dimensions (LĆWĆH) |
370.4mmĆ124.7mmĆ105.7mm (14.58”Ć4.91”Ć4.16”) |
| Net Weight |
1.7kg (3.75lb) |
| Gross Weight |
2.5kg (5.51lb) |
| Installation |
Universal joint installation |
| Lens |
10mmā50mm (0.39”ā1.97”) |
