System Parameters
Storage: cards information:
100,000 (200,000 expandable)
access control events :
300,000 (600,000 expandable)
Capacity: 16M
Processor: 32-bit
Device Interfaces
Output Interface: Lock RelayƗ2, Alarm RelayƗ4
Uplink Communication Interface: TCP/IP Network Interface and RS-485 Interface
Input Interface: Alarm InputƗ4,Door SensorƗ2,Exit ButtonƗ2,Case InputƗ4,Tamper AlarmƗ1
Downlink Communication Interface: RS-485 and Wiegand (W26/W34)
General
Indicator: 7 Indicators (RS-485 Communication Status*2, Power Supply*1,
Exit Button*1, Lock Status*1, Door Magnetic*1 and Running
Status*1)
Working Voltage: DC 12V/1A
Power Consumption: ā‰¤4W(Without Load); ā‰¤100W(with Load)
Working Humidity: 10% to 90% (Non-Condensing)
Working Temperature : -20Ā°C to +65Ā°C (-4Ā°F to +149Ā°F)
