| Camera |
|
|
|
|
| Image Sensor |
|
1/3″ Progressive Scan CMOS |
|
|
|
|
|
|
| Min. Illumination |
|
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR |
|
|
|
|
|
|
| Shutter Speed |
|
1/3 s to 1/10,000 s |
|
|
|
|
|
|
| Lens |
|
2.8mm, 4mm @ F2.0 |
|
|
|
|
|
|
| Lens Mount |
|
M12 |
|
|
|
|
|
|
|
| Day &Night |
|
IR cut filter with auto switch |
|
|
|
|
|
|
| DNR |
|
3D DNR |
|
|
|
|
|
|
|
| Wide Dynamic Range |
|
120dB |
|
|
|
|
|
|
|
| Angle of adjustment |
|
Pan: -30° ~ 30°, Tilt: 0 ~ 75°, Rotation: 0 ~ 360° |
|
|
|
|
|
|
| Compression Standard |
|
|
|
|
| Video Compression |
|
H.264 / MJPEG/H.264+ |
|
|
|
|
|
|
| H.264 Type |
|
Main Profile |
|
|
|
|
|
|
| Video Bit Rate |
|
32 Kbps ~ 16 Mbps |
|
|
|
|
|
|
| Dual Streams |
|
Support |
|
|
|
|
|
|
| Audio Compression |
|
G.711/G.722.1/G.726/MP2L2 *only for –S models |
|
|
|
|
|
| Audio Bit rate |
|
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) *only for –S models |
|
|
|
|
|
|
| Image |
|
|
|
|
| Max. Resolution |
2688Ă—1520 |
|
|
|
|
|
|
| Frame Rate |
|
50Hz: 20fps (2688Ă—1520), 25fps(1920Ă—1080), 25fps(1280Ă—720) |
|
|
60Hz: 20fps (2688Ă—1520), 30fps (1920Ă—1080), 30fps(1280Ă—720) |
|
|
|
|
|
|
|
|
| Image Setting |
|
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
|
|
|
|
|
| BLC |
|
Support, zone configurable |
|
|
|
|
|
|
| ROI Codec |
|
Support |
|
|
|
|
|
|
|
| Network |
|
|
|
|
| Network Storage |
|
NAS (Support NFS,SMB/CIFS), ANR |
|
|
|
|
|
| Alarm Trigger |
|
Intrusion detection, Line crossing detection, Motion detection, Dynamic analysis, Tampering alarm, Network |
|
|
disconnect, IP address conflict, Storage exception |
|
|
|
|
|
|
|
|
|
| Protocols |
|
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, |
|
|
IGMP, 802.1X, QoS, IPv6, Bonjour |
|
|
|
|
| General |
|
One-key reset, |
Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, |
|
|
watermark, IP address filtering, Anonymous access |
|
|
|
|
|
|
|
|
| Standard |
|
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
|
| Interface |
|
|
|
|
| Communication |
|
1 RJ45 10M/100M Ethernet port |
|
| Interface |
|
|
|
|
|
|
| On-board storage |
|
Built-in Micro SD/SDHC/SDXC slot, up to 128GB |
|
|
|
|
|
|
| Alarm interface |
|
1x alarm I/O |
*only for –S models |
|
|
|
|
|
| Audio interface |
|
Built-in microphone and 1x audio output *only for –S models |
|
|
|
|
|
|
| Reset |
|
Yes |
|
|
|
|
|
|
|
|
Wireless Standards |
IEEE802.11b, 802.11g, 802.11n |
|
|
|
|
|
|
Frequency Range |
2.4 GHz ~ 2.4835 GHz |
|
|
|
|
|
|
Channel Bandwidth |
20/40MHz Support |
|
|
|
|
|
|
Protocols |
802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
|
|
|
|
|
|
Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
|
|
|
|
|
|
|
11b: 17±1.5dBm @ 11Mbps |
|
|
Transmit Output Power |
11g: 14±1.5dBm @ 54Mbps |
|
|
|
11n: 12.5±1.5dBm |
|
|
|
|
|
|
|
11b: -90dBm @ 11Mbps (Typical) |
|
|
Reception Sensitivity |
11g: -75dBm @ 54Mpbs (Typical) |
|
|
|
11n: -74dBm (Typical) |
|
|
|
|
|
|
Transfer Rates |
11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps |
|
|
|
|
|
|
Wireless Range |
50 meters *The performance varies based on actual environment. |
|
|
|
|
|
|
General |
|
|
|
|
|
|
|
Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140°F), Humidity 95% or less (non-condensing) |
|
|
|
|
|
|
Power Supply |
DC12V ± 10%, PoE (802.3af) |
|
|
|
|
|
|
Power Consumption |
Max. 5W |
|
|
|
|
|
|
IR Range |
Approx. 10 meters |
|
|
|
|
|
|
Ingress Protection |
IP66 |
|
|
|
|
|
|
Impact Protection |
IEC60068-275Eh, 20J; EN50102, up to IK08 |
|
|
|
|
|
|
Dimensions |
99.3Ă—96.7Ă—52.8 mm |
|
|
|
|
|
|
Weight |
600 g (1.32 lbs) |
