Thermal Module
Image sensor: Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution: 384*288
Detector Pitch: 17um
Response Wavebond: 8um to 14um
NETD: < 35mk(@25°C,F#=1.0)
Lens (focal length): 7mm
MRAD: 2.43 mrad
Field of View: 60°x 43.80°
Min. Focusing Distance: 0.8m
F number: 1.0
Smart Function
VCA: Support 4 VCA rule types (Line Crossing, Intrusion, Region Entrance, and Region Exiting), 8 VCA
rules
Temperature Measurement: Support 3 temperature measurement rule types, over 256 presets as scene, 21 rules of each scene (10
points, 10 regions, and 1 line)
Temperature Range: -20 ° C to 150 ° C (-4 ° C to 302 ° F)
Temperature Accuracy: ±8 ° C (14.4 ° F)
Fire Detection: Support 10 fire points
Network
Main Stream: 50fps(384 × 288)
Sub Stream: 50fps(384 × 288)
Third Stream: 50fps(384 × 288)
Video Compression: H.265/H.264/MJPEG, H.265+, H.264+ encoding with Baseline/Main/High Profile
Audio Compression: G .711u/G.711a/G.722.1/MP2L2/G.726/PCM
Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS,NTP, RTSP,RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Simultaneous live view: Up to 20-ch
User/Host Level: Up to 32 users, 3 levels: Administrator, Operator, User
Security Measures: User authentication (ID and PW), MAC address binding, HTTPS encryption, IEEE 802.1x access control,
IP address filtering
Integration
Alarm Input: 2-ch Inputs (0-5V DC)
Alarm Action: Preset/Patrol Scan/Pattern Scan/SD Card Record/Relay Output/Smart capture/FTP upload/Email
linkage
Alarm Output: 2-ch relay outputs, alarm response actions configurable
Audio Input: 1-ch 3.5mm Mic in/Line in interface. Line input: 2-2.4 V[p-p], output impedance:1KΩ±10%
Audio Output: Linear Level; Impedance: 600Ω
Communication Interface: Built-in RJ45; 10M/100M Ethernet Interface
Onboard Storage: Built-in Micro SD/SDHC/SDXC Card Slot, Up to 64GB; Support Manual/Alarm Recording
Ethernet: 1 RJ45 10M/100M Self-adaptive Ethernet interface
Analog Video Output: 1.0V [p-p]/75Ω, PAL/NTSC/BNC
Application Programming: Open-ended API, support ISAPI; Support HIKVISION SDK and Third-party Management Platform
Client: iVMS-4200
Web Browser: IE9+, chrome31-chrome44, Firefox 30-Firefox51, Safari 5.02+(mac)
General
Power Consumption: 24 VAC± 25%: 0.84 A, 12 VDC ± 20%: 1.7 A, max. 8W (20W with De-icing Heater On),
PoE (802.3at, class 4): 42.5 V to 57 V, 0.4 A to 0.5 A
Power: 24 VAC± 25%, 12 VDC± 20%, two-core terminal block PoE (802.3at, class 4)
Menu Language: English
Working Temperature/ Humidity: From -40 ° C to 65 ° C (-40 ° F to 149 ° F); Humidity: 90% or Less
Protection Level: IP66 Standard; TVS 6000V Lightning Protection, Surge Protection and Voltage Transient Protection
Dimensions: 352.4mm × 113.5mm × 113mm (13.9″ × 4.45″ × 4.45″)
Weight: 2kg (4.41lb)
Smart Functions Range
Lens (focal length): 7mm
VCA range (Vehicles): 210m
VCA range (humans): 70m
Temperature measurement (Object:2*2m): 164m
Temperature measurement (Object:1*1m): 83m
Fire Detection (Object:2× 2 m): 412m
Fire Detection (Object:1× 1 m): 206m
Wide Range Coverage
Lens (focal length): 7mm
Detection range (Vehicles): 631m
Detection range (Humans): 206m
Recognition range (Vehicles): 158m
Recognition range (Humans): 51m
Identification range (Vehicles): 79m
Identification range (Humans): 26m
