- System Parameters
- Operation Method One touch key
- Operation System Embedded Linux operation system
- Processor Embedded microcontroller
- Alarm Parameters
- Relay Output 2, NC + NO separately draw forth
- Network Parameters
- Network Protocol TCP/IP, RTSP
- Wired Network Interface Two-wire transmission
- Video Parameters
- Video Compression Standard H.264
- Video Streaming Main stream: 1080p@30fps, 720p@30fps (configurable)͖’ sub stream: D1
- Resolution Main stream: 1920 × 1080, (720p configurable); sub stream: 720 × 480
- Night Vision Support low light and IR lightsupplement mode
- BLC Support
- Anti-Flicker Frequency 50 Hz, 60 Hz
- Camera 2MP super definition camera
- Field Of View Horizontal 180°, vertical 96°
- Wide Dynamic Range Real wide dynamic
- Device Interfaces
- Alarm Input 4
- Audio Parameters
- Audio Compression RateG.711 U
- Audio Compression Standard64 Kbps
- Audio Input Omnidirectional microphone
- Audio Output Loudspeaker, 20 cm sound effect> 80db
- Audio Quality Noise suppression and echo cancellation
- Audio Intercom Full-duplex two-way audio intercom
- General
- Protection Level IP 65
- Button 1
- Power Input 24 VDC two-wire power supply (< 16 W) or 12 VDC independent power supply (< 20 W)
- Working Temperature -40 °C to 60 °C (-40 °F to 140 °F)
- Working Humidity 10% to 95%
- Installation Wall mounting
- Power Output 12 VDC (only for power supply of submodule)
- Tamper 1
