Uniview IPC2328SB-DZK-I0 8MP LightHunter Motorised Bullet Camera, IR50m, IP67, IK10, WDR, PoE

The Uniview IPC2328SB-DZK-I0 8MP LightHunter Motorised Bullet Camera is designed to deliver high-quality surveillance footage. Equipped with a 1/2.8″ CMOS sensor, it supports resolutions up to 3840×2160 at 20fps and offers multiple video compression formats including Ultra 265, H.265, H.264, and MJPEG. The camera features smart intrusion prevention capabilities, such as cross line, intrusion, enter area, and leave area detection, effectively reducing false alarms by accurately identifying humans, motor vehicles, and non-motor vehicles. Its LightHunter technology ensures superior image quality in low-light conditions, while the 120dB true WDR technology provides clear images in high-contrast lighting scenarios. Additional features include support for 9:16 Corridor Mode, smart IR with up to 50m (164ft) IR distance, a 512GB Micro SD card slot, IK10 vandal resistance, IP67 protection, and PoE power supply support.

Key Features:

High quality image with 8MP, 1/2.8″ CMOS sensor
8MP (3840×2160) @20fps; 5MP (3072×1728) @30/25fps; 4MP (2560×1440) @30/25fps; 2MP (1920×1080) @30/25fps
Ultra 265, H.265, H.264, MJPEG
Smart intrusion prevention, including cross line, intrusion, enter area, and leave area detection
Based on target classification, smart intrusion prevention significantly reduces false alarms caused by leaves, birds, lights, etc., accurately focusing on humans, motor vehicles, and non-motor vehicles
Intelligent People Flow Counting and Crowd Density Monitoring
LightHunter technology ensures ultra-high image quality in low illumination environments
120dB true WDR technology enables clear images in strong light scenes
Supports 9:16 Corridor Mode
Alarm: 1 input / 1 output, Audio: 1 input / 1 output
Smart IR, up to 50m (164ft) IR distance
Supports 256 GB Micro SD card
IK10 vandal resistant
IP67 protection
Supports PoE power supply

IPC2328SB-DZK-I0 Datasheet

$344.37 inc GST +3 Year Warranty & Support

Description

The Uniview IPC2328SB-DZK-I0 is an 8-megapixel LightHunter IR bullet network camera designed to deliver high-quality surveillance footage. Equipped with a 1/2.8″ CMOS sensor, it captures video at resolutions up to 3840 x 2160 pixels at 20 frames per second. The camera features a motorized 2.8-12mm varifocal lens, offering a horizontal field of view ranging from 107.4° to 29.2°, allowing for flexible monitoring of various environments. Its LightHunter technology ensures exceptional image clarity in low-light conditions, while the 120dB true Wide Dynamic Range (WDR) effectively balances exposure in scenes with strong lighting contrasts. Additionally, the camera’s Smart IR capabilities provide night vision up to 50 meters (164 feet), enhancing its performance in complete darkness.

Beyond its imaging capabilities, the IPC2328SB-DZK-I0 offers advanced intelligent features such as smart intrusion prevention, which includes cross line, intrusion, enter area, and leave area detection. This functionality significantly reduces false alarms by accurately identifying humans, motor vehicles, and non-motor vehicles, minimizing disturbances caused by environmental factors like leaves or lights. The camera also supports intelligent people flow counting and crowd density monitoring, providing valuable data for managing public spaces. Built to withstand challenging conditions, it boasts an IK10 vandal resistance rating and IP67 weatherproof protection, ensuring durability against physical impacts and harsh weather. Power over Ethernet (PoE) support simplifies installation by allowing both power and data transmission through a single cable.

Technical Specifications:

Camera
Sensor	1/2.8″, 8.0 megapixel, progressive scan, CMOS
Minimum Illumination	Colour: 0.0025 lux (F1.6, AGC ON) 0 lux with IR on
Day/Night	IR-cut filter with auto switch (ICR)
Shutter	Auto/Manual, 1 ~ 1/100000s
Adjustment angle	Pan: 0° ~ 360°		Tilt: 0° ~ 90°			Rotate: 0° ~ 360°
WDR	120dB
S/N	>56 dB
Lens
Lens	2.8 ~ 12mm, AF automatic focusing and motorized zoom lens
Iris	Fixed
Field of View (H)	107.4°~ 29.2°
Field of View (V)	54.2°~ 16.3°
Field of View (D)	111.0°~33.1°
DORI
DORI Distance	Lens (mm)	Detect (m)		Observe (m)	Recognize (m)		Identify (m)
	2.8	86.9		34.8	17.4		8.7
	12	372.4		149.0	74.5		37.2
Illuminator
IR Range	Up to 50m (164ft) IR range
Wavelength	850nm
IR On/Off Control	Auto/Manual
Video
Video Compression	Ultra 265, H.265, H.264, MJPEG
H.264 code profile	Baseline profile, Main profile, High profile
Frame Rate	Main Stream: 8MP (38402160), Max 20fps;5MP (30721728), Max 30fps; 4MP (25601440), Max30fps; 1080P (19201080), Max 30fps; Sub Stream: 1080P (19201080), Max 30fps;720P (1280720), Max 30fps; D1 (720576), Max 30fps; 640360,Max 30fps; 2CIF(704288), Max 30fps; CIF(352288), Max 30fps; Third Stream: D1 (720576), Max 30fps; 640360,Max 30fps; 2CIF(704288), Max 30fps; CIF(352288), Max 30fps;
Video Bit Rate	128 Kbps~16 Mbps
U-code	Support
OSD	Up to 8 OSDs
Privacy Mask	Up to 4 areas
ROI	Up to 8 areas
Video Stream	Triple streams
White Balance	Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Smart IR	Support
Flip	Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
Dewarping	Support
HLC	Support
BLC	Support
Defog	Digital Defog
Intelligent
Smart intrusion prevention	Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection
Statistical Analysis	People counting, support people flow counting and crowd density monitoring
Events
Basic Detection	Motion detection, Ultra motion detection, Tampering alarm, Audio detection
General Function	Watermark, IP address filtering, tampering alarm, alarm input, alarm output, access policy, ARP protection, RTSP authentication, user authentication
Audio
Audio Compression	G.711
Audio Bitrate	64 Kbps
Two-way audio	Support
Suppression	Support
Sampling Rate	8KHZ
Storage
Edge Storage	Micro SD, up to 256GB
Network Storage	ANR, NAS(NFS)
Network
Protocols	IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS, SSH
Compatible Integration	ONVIF (Profile S, Profile G, Profile T), API,SDK
User/Host	Up to 32 users. 2 user levels: administrator and common user
Security	Password protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Client	EZStation EZView EZLive
Web Browser	Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
	Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
Interface
Audio I/O	Input: impedance 35kΩ; amplitude 2V [p-p]
	Output: impedance 600Ω; amplitude 2V [p-p]
Alarm I/O	1/1
RS485	N/A
Built-in Mic	N/A
Built-in Speaker	N/A
WIFI	N/A
Network	1 * RJ45 10M/100M Base-TX Ethernet
Video Output	N/A
Certifications
EMC	CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
Safety	CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
Environment	CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection	IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002)
General
Power	DC 12V±25%, PoE (IEEE 802.3af)
	Power consumption: Max 10.5W
Power Interface	Ø 5.5mm coaxial power plug
Dimensions (L × W × H)	245 × 86 × 72mm (9.6” × 3.4” × 2.8”)
Weight	0.92kg (2.03lb)
Material	Metal
Working Environment	-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment	-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection	6KV
Reset Button	N/A
