ZKTeco ZK-IDTAG TK4100, 125KHz Proximity Tag

The ZKTeco CR20M is a desktop USB RFID card reader designed for efficient enrollment and management of Mifare 13.56MHz proximity cards. It connects to a PC via a USB port, enabling plug-and-play functionality without the need for additional drivers. The device supports high-speed transactions and features dual-color LED indicators (red and green) along with an integrated beeper for user feedback. With a reading range of up to 3 centimeters, the CR20M operates at a frequency of 13.56MHz and consumes a maximum of 60mA at 5V DC. Its compact design, measuring 117.2×66.2×17 mm and weighing 120 grams, is constructed from durable ABS+PC materials in black.

The CR20M is compatible with Windows operating systems, including WIN98, 2000, XP, Vista, and 7, functioning as a keyboard emulation device. This compatibility allows the reader to input card numbers directly into the cursor’s position in decimal format, streamlining the card enrollment process and reducing manual entry errors. The device operates effectively in temperatures ranging from -10ºC to +70ºC and supports operating humidity levels between 10% to 90% (non-condensing). These features make the CR20M a reliable and user-friendly solution for contactless card enrollment in various access control and time attendance systems.

Key Features:

• Available for 13.56MHz credentials
• USB charging
• Plug & play
• LED indicator and buzzer feedback
• Industrial Class ABS plastic

The ZKTeco INBIO 160 PRO 1-Door Network Controller Panel is an IP-based biometric access control solution designed to manage a single door with advanced security features. It supports up to four readers, including two RS485 readers and two 26-bit Wiegand readers, providing flexibility in reader integration. The controller can accommodate up to 20,000 fingerprint templates and 60,000 cardholders, ensuring scalability for various organizational needs. With a storage capacity of up to 100,000 log events, it maintains comprehensive access records. Communication is facilitated through TCP/IP, allowing seamless integration into existing network infrastructures.

In addition to basic door control, the INBIO 160 PRO offers advanced access control functionalities such as Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and auxiliary input/output linkages. These features enhance security by providing tailored access protocols and responses to specific scenarios. The controller’s firmware is upgradeable without the need for advanced tools, ensuring that the system can adapt to evolving security requirements. Designed for reliability, it operates within a temperature range of 0°C to 45°C and supports an operating humidity of 20% to 80%. This makes the INBIO 160 PRO a versatile and robust solution for secure access management in various environments.

Key Features:

• Support different types of readers. The FR Series of readers transmit fingerprint templates to inBio Pro via RS485. Wiegand inputs are also provided for traditional RFID readers
• More than Door Control. Access additional control and interface with auxiliary relays
• Communication. Can be installed easily on your network and support both HTTP/HTTPS communication
• Capacity. Support up to 20000 fingerprint templates, 60,000 cards and store up to 100,000 events and transactions
