The ZKTeco inBio-260 Pro is an IP-based biometric door access control panel designed to manage security for two doors. It supports up to eight readers, including four RS485 fingerprint readers and four 26-bit Wiegand readers, offering flexibility in reader integration. The system can store up to 20,000 fingerprint templates, 60,000 cardholders, and log 100,000 events and transactions, ensuring robust data management. Communication is facilitated through TCP/IP, allowing seamless integration into existing network infrastructures. Advanced access control features such as Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and auxiliary input/output linkages are built into the controller firmware, enhancing security measures.

The inBio-260 Pro is equipped with a 32-bit 1.2GHz CPU, 128MB RAM, and 256MB flash memory, ensuring efficient processing and storage capabilities. It operates within a power range of 9.6V-14.4V DC and functions optimally in temperatures between 0°C and 45°C, with an operating humidity of 20% to 80%. The controller’s firmware is upgradable without the need for advanced tools, ensuring the system remains current with the latest features and security enhancements. Additionally, the inBio-260 Pro offers more than just door control; it provides access to additional controls and interfaces with auxiliary relays, allowing integration with lights, alarms, and intrusion detection panels.

Key Features:

• Support different types of readers. The FR Series of readers transmit fingerprint templates to inBio Pro via RS485. Wiegand inputs are also provided for traditional RFID readers
• More than Door Control. Access additional control and interface with auxiliary relays
• Communication. Can be installed easily on your network and support both HTTP/HTTPS communication
• Capacity. Support up to 20000 fingerprint templates, 60,000 cards and store up to 100,000 events and transactions
• Advanced Access Control Built-In. Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and Auxiliary input/output linkages are built into controller firmware
• Lowest Total Cost of Ownership. Controller firmware can be upgraded without any advanced tools

The ZKTeco INBIO 460 PRO is a four-door network controller panel designed to enhance security through advanced biometric identification. It supports up to 12 readers, accommodating both RS-485 and 26-bit Wiegand protocols, allowing for flexible integration with various reader types. The controller manages up to 60,000 cardholders and 20,000 fingerprint templates, ensuring scalability for large organizations. With TCP/IP communication, it seamlessly integrates into existing network infrastructures for efficient data transmission. Additionally, the INBIO 460 PRO offers advanced access control features such as Anti-Passback, First-Card Opening, Multi-Card Opening, and Duress Password Entry, enhancing overall security measures.

This controller is equipped with 12 input ports for exit buttons, door status sensors, and auxiliary inputs, alongside eight output relays for locks and auxiliary devices, providing comprehensive control over access points. Its embedded fingerprint matching technology ensures accurate and swift user verification, enhancing security protocols. The INBIO 460 PRO‘s firmware is field-upgradable, allowing for continuous improvement and feature expansion without the need for advanced tools. Its compatibility with ZKBioSecurity web-based software enables centralized management of access control systems. Overall, the INBIO 460 PRO is a robust solution for organizations seeking to implement reliable and scalable access control systems.

Key Features:

• Support different types of readers. The FR Series of readers transmit fingerprint templates to inBio Pro via RS485. Wiegand inputs are also provided for traditional RFID readers
• More than Door Control. Access additional control and interface with auxiliary relays
• Communication. Can be installed easily on your network and support both HTTP/HTTPS communication
• Capacity. Support up to 20000 fingerprint templates, 60,000 cards and store up to 100,000 events and transactions

The ZKTeco AHEB-0808 IO Expansion Board is designed to enhance the capabilities of access control systems, particularly when integrated with the Atlas Panel. This expansion board provides eight supervised inputs and eight relay outputs, facilitating the monitoring of additional devices and sensors, and enabling the activation of external devices. It supports OSDP V2.2 communication over RS-485, ensuring secure and reliable data transmission between the board and controllers such as the AHSC-1000 or AHDU series. The AHEB-0808’s scalability allows for future system expansions, making it a versatile choice for various security applications.

Incorporating the AHEB-0808 into an access control setup offers several benefits, including supervised input states with time zone management, allowing for precise control and monitoring of security events. Its compatibility with third-party systems is facilitated through a RESTful API, supporting seamless integration with existing building management systems using protocols like OPC, BACnet, and Modbus. The board’s design adheres to high-security standards, featuring AES-128 encryption for RS-485 communication and compliance with certifications such as CE, FCC, RoHS, and UL294. This ensures that the AHEB-0808 meets rigorous industry requirements, providing a robust and secure solution for expanding access control system functionalities.

Key Features:

• Scalability: Supports up to 384 inputs and 385 outputs with a single AHDU controller and up to 12,801 inputs or outputs with a combination of AHSC-1000 and AHDU series controllers.
• Supervised Inputs: Equipped with 8 supervised inputs that support 4-state monitoring, capable of detecting resistance values with 5% tolerance.
• Relay Outputs: Features 8 Form-C relay outputs with dry contacts, allowing for versatile control of connected devices.
• OSDP Communication: Utilizes OSDP V2.2 protocol over RS-485 for secure and reliable communication with controllers like the AHSC-1000 and AHDU series.

The ZKTeco EP10C is an all-weather, multi-technology smart reader designed for robust outdoor access control applications. It supports over 100 RFID card types across multiple frequencies, including 125 kHz, 13.56 MHz (ISO14443A types A & B, ISO15693), and 2.4 GHz Bluetooth, enabling compatibility with a wide range of credentials. The device features both RFID and Bluetooth functionalities, offering versatile access options. Its compact design is suitable for mullion-mount door installations or any flat surface mounting, with optional single-gang box configurations to accommodate various installation environments.

Built to withstand harsh conditions, the EP10C boasts an IP68 rating for water and dust resistance, IK10 certification for vandal resistance, and compliance with the UL94-V0 flame-retardancy standard. It operates effectively in temperatures ranging from -22°F to 158°F (-30°C to 70°C), ensuring reliable performance in diverse climates. The reader communicates via Wiegand (up to 128 bits SCP secure communication) or OSDP (v2.2) through RS485, ensuring secure data transmission. Additional features include configurable RGB LEDs and an internal buzzer with adjustable intensity, both manageable via the ‘Armatura Connect’ mobile app. The EP10C also incorporates a magnetic tamper detection system for enhanced security.

Key Features:

• Multi-tech RFID & Mobile Credential
• IP68 Water & Dustproof Protection Level
• IK10 Physical & Environmental Protection
• Supports 100+ Card Types
• UL 94V-0 Flame-Retardancy Level Standard
• Compact Mullion Mount with Optional Gang Box

The ZKTeco QR600-V is a robust QR code and RFID card reader designed for secure access control applications. Housed in a metal casing with an IP65 rating, it is both waterproof and dustproof, making it suitable for various environmental conditions. The device supports dynamic QR code recognition through the ZKBioSecurity Mobile Application, enhancing user convenience and security. It is compatible with multiple QR code formats, including QR, Data Matrix, and PDF417, and supports RFID cards operating at 125kHz and 13.56MHz frequencies. The QR600-V offers flexible integration options with Wiegand and RS485 communication interfaces.

This reader features a reading distance of up to 5 centimeters for QR codes and 4 centimeters for RFID cards, ensuring quick and efficient access. It operates reliably in temperatures ranging from -20°C to 60°C and humidity levels between 20% and 80%, adapting well to diverse environments. Measuring 138mm in length, 58mm in width, and 16mm in height, the QR600-V‘s compact design facilitates easy installation in various settings. Its compatibility with dynamic QR codes and encrypted solutions provides a versatile access choice for a wide range of scenarios, including residential communities, visitor management, hotel management, and more.

Key Features:

• Rugged waterproof IP 65 metal case
• Keypad (QR600-HK and QR600-VK)
• Compatible with Dynamic QR codes Solutions on ZKBioSecurity and Atlas Series
• QR code, PDF417, Data Matrix, MicroPDF417, Aztec
• Communication: Wiegand & RS485
• Supports 125kHz ID Cards or 13.56MHz IC Cards, which includes Ultralight, Mifare (S50/S70), CPU, NFC (analog Card), Desfire EV1, NTag

Flush-Mounted RS-485 Fingerprint Reader

Key Features:

• SilkID Fingerprint Sensor with support for Live Finger Detection
• D2S RS-485 Communication Interface
• D2S Optional Fingerprint Protective Cover
• D2S Single-Gang Standard Junction Box Installation

The SLK20R is a high-performance fingerprint scanner developed by the ZKTeco USA laboratory, featuring an advanced optical design. Equipped with a 2-megapixel camera, it excels in live fingerprint detection and captures high-quality fingerprint images. This device offers a comfortable and cost-effective solution for desktop enrollment and identification.

Key Features:

• USB 2.0
• Quick recognition of dry, wet and rough fingerprints
• Available SDK for further development

The ZKTeco EX16 Elevator Floor Extension Board is designed to enhance elevator access control by adding management capabilities for up to 16 additional floors. When integrated with the EC10 Elevator Control Panel, which independently manages up to 10 floors, a single EC10 can support up to three EX16 boards, collectively controlling access to a total of 58 floors. This scalability offers a comprehensive solution for multi-story buildings requiring precise access management. The EX16 ensures seamless integration, making it ideal for both small and large-scale elevator systems. It provides an efficient and secure way to extend elevator access control without requiring a complete system overhaul.

The EX16 communicates with the EC10 via RS485, ensuring reliable data transmission. It supports various user credentials, including fingerprints, proximity cards, and passwords, providing flexible authentication methods to suit diverse security needs. Additionally, pre-defined time schedules can be implemented to control floor access, and during regular business hours, unrestricted access (passage mode) can be enabled for convenience. The extension board is designed with durability and efficiency in mind, ensuring long-term performance in commercial and residential buildings. With its advanced security features and seamless compatibility, the EX16 is a valuable addition to any modern elevator access control system.

Key Features:

• 16 floors controlled with EX16
• When combining EC10 together with 3*EX16 panel, a total fifty eight (58) floors can be controlled with a single EC10 bundle
• RS485 communication
