The ZKTeco Atlas100 is a state-of-the-art 1-door access control panel designed for seamless security management. It supports up to two readers, compatible with ZKTeco KR Series and third-party 125kHz and 13.56MHz Wiegand, OSDP, and RS-485 readers, providing flexibility in reader selection. The device features three inputs—Exit Button, Door Sensor, and Auxiliary—and two outputs, including a Form C relay for lock control and an auxiliary output, ensuring comprehensive access control capabilities. With a user capacity of 5,000 and the ability to log up to 10,000 transactions, the Atlas100 is suitable for small to medium-sized installations.

One of the standout features of the Atlas100 is its built-in web application, eliminating the need for additional management software and allowing for user enrollment, door monitoring, and reporting directly through web browsers like Chrome, Firefox, and Edge. The panel supports both TCP/IP and optional Wi-Fi communication, ensuring secure and flexible network integration. Power options include a 12V DC, 3A supply or Power over Ethernet (PoE), simplifying installation by reducing the need for separate power lines. The durable powder-coated aluminum enclosure and wall-mount design make it suitable for various environments. Additionally, the Atlas100 can be managed remotely via a mobile app, offering features like door unlocking, lockdown recovery, and user management, enhancing convenience for administrators.

Key Features:

• Advanced Access Control Features – built-in Web Application provides such features including User Enrollment & Management, Door Control & Monitoring, Lockdown, Reporting, Maps, Anti-Passback, First-Card Opening, Multi-Card Opening, Card Design and Duress PINs.
• Choice of Readers – supports ZKTeco KR Series readers and additionally any 3rd-party readers with Wiegand or OSDP communication protocols.
• Door Control and More – user-programmable auxiliary relays can be used to control lights, alarms, annunciators, intrusion detection panels, additional locking devices, or any other external electrical device which can be controlled by a switch.
• Capacity – 1 Primary panel can support up to 20 Secondary panels. Maximum 84 doors can be supported when using all 21 panels. Each Atlas Prox Series panel can store up to 5,000 users & 10,000 transactions plus unlimited archive downloads.
• Communication – Atlas Prox Series panels communicate securely over wired & wireless TCP/IP networks using SSL/TLS. Supported browsers include Google Chrome, Mozilla Firefox and Microsoft Edge
• Mobile App – numerous features include: remotely unlocking doors, universal lockdown & recovery, access to events & alarms, adding/modifying users, and much more.
• Power – Atlas Bio Series uses a 12V DC 3A power supply and also supports Power over Ethernet (PoE).
• Lowest Total Cost of Ownership – Atlas Prox Series panels come in several models to suit different project needs and reduce the cost of unused capacity.

The Atlas-200 is a 2-door access control panel with an integrated web-based application, eliminating the need for additional management software. The Atlas Prox Series is compatible with any third-party readers that support Wiegand, RS485, or OSDP communication protocols.

Key Features:

• Advanced Access Control – The built-in web application offers robust features, including user enrollment & management, door control & monitoring, lockdown functionality, reporting, interactive maps, anti-passback, first-card/multi-card opening, card design, and duress PINs.
• Reader Compatibility – Supports ZKTeco KR Series readers and third-party readers utilizing Wiegand or OSDP protocols.
• Comprehensive Door Control – User-programmable auxiliary relays can operate lights, alarms, annunciators, intrusion detection panels, additional locking devices, or any other switch-controlled electrical device.
• Scalability & Capacity – A primary panel can support up to 20 secondary panels, allowing management of up to 84 doors across 21 panels. Each panel can store 5,000 users and 10,000 transactions, with unlimited archive downloads.
• Secure Communication – Atlas Prox Series panels communicate securely via wired and wireless TCP/IP networks using SSL/TLS encryption. Compatible with Google Chrome, Mozilla Firefox, and Microsoft Edge.
• Mobile App Integration – Offers remote access control features such as unlocking doors, universal lockdown & recovery, real-time event & alarm monitoring, and user management.
• Power Options – Operates on a 12V DC 3A power supply and supports Power over Ethernet (PoE) for flexible installation.
• Cost-Effective Solution – Available in multiple models to accommodate various project needs, minimizing unnecessary costs while maximizing functionality.

Designed specifically for elevator control, the EC10 panel and EX16 floor extension boards offer customers a secure, scalable, versatile, and cost-effective access control solution. Floor access can be restricted based on various user credentials, including fingerprints, proximity cards, and passwords. Additionally, predefined time schedules can be set to regulate access. During normal business hours or scheduled visits, unrestricted floor access (also known as Passage Mode) can be enabled.

The EC10 Elevator Control Panel manages access to up to ten floors, while the EX16 Elevator Floor Extension Board adds control for up to sixteen additional floors. Each EC10 panel supports up to three EX16 boards, allowing a single EC10 bundle to control a total of 58 floors. Furthermore, multiple EC10 panels can be daisy-chained together to accommodate buildings of any size.

Our powerful yet user-friendly software simplifies system management, and an SDK is available for software companies looking to integrate the system into their own platforms.

Key Features:

EC10 Elevator Control Panel:

• Controls access to up to 10 floors.
• Supports various user credentials: fingerprint, proximity card, and/or password.
• Allows pre-defined time schedules for floor access control; Passage mode permits unrestricted access during normal business hours.
• Supports up to 3 EX16 boards, enabling control of up to 58 floors when combined.
• Multiple EC10 panels can be daisy-chained to manage additional floors as needed.
• Fingerprint capacity: 3,000.
• RFID card capacity: 30,000.
• Event capacity: 100,000.
• Communication interfaces: TCP/IP and RS485.
• Dimensions: 242mm × 95mm × 60mm; weight: 0.8kg.

EX16 Elevator Floor Extension Board:

• Extends control to an additional 16 floors per board.
• Up to 3 EX16 boards can be connected to a single EC10 panel, allowing control of up to 58 floors.
• Communicates with EC10 via RS485 interface.
• RS485 address set by DIP switch.
• Power supply: 12V DC 1A.
• Dimensions: 160mm × 106mm; weight: 0.2kg.

The ZKTeco EC10 Elevator Control Panel is a specialized solution designed to enhance elevator security and access management. It allows restriction of access to up to ten floors, utilizing various user credentials such as fingerprints, proximity cards, or passwords. To accommodate buildings with more floors, the EC10 can be expanded by connecting up to three EX16 Elevator Floor Extension Boards, each managing an additional sixteen floors, thereby enabling control of up to fifty-eight floors with a single EC10 setup. For larger installations, multiple EC10 panels can be daisy-chained to manage an even greater number of floors.

The EC10 boasts a fingerprint capacity of 3,000, supports up to 30,000 RFID cards, and can log up to 100,000 events, ensuring robust performance for high-traffic environments. It communicates with PCs via TCP/IP or RS485 interfaces and connects to EX16 boards through RS485. The system supports pre-defined time schedules to control floor access and offers a passage mode for unrestricted access during designated hours. For software developers aiming to integrate the EC10 into broader systems, an SDK is available, facilitating seamless customization and integration.

Key Features:

• Floor access can be restricted based on various user credentials, including fingerprint, proximity card and/or password
• Pre-defined time schedules can be used to control floor access. During normal visits/business hours, unrestricted floor access can also be permitted (aka Passage mode)
• When combining together with EX16 panel, a total fifty eight (58) floors can be controlled with a single EC10 bundle
• EC10 panels can be daisy-chained together to control as many floors as desired
• SDK is available for software companies which desire to integrate with the system

The ZKTeco KF1200[IC] is an advanced visible light facial recognition and card reader designed to enhance security and access control systems. It supports up to 1,500 facial templates and 30,000 cardholders, ensuring rapid and accurate identification with a recognition speed of less than 0.3 seconds. The device operates effectively within a recognition distance of 30 to 50 centimeters, maintaining a false acceptance rate (FAR) of less than 0.001% and a false rejection rate (FRR) under 1%. Equipped with ZKTeco’s ZKLiveface 3.5 algorithm, the KF1200[IC] offers one of the fastest, most stable, and accurate facial recognition experiences in the industry.

For seamless integration, the KF1200[IC] features multiple communication options, including TCP/IP, Wiegand output, and RS485 (upcoming). It also includes an on-board web server for easy system configuration. The device is fully compatible with ZKTeco’s inBio Series controllers and the ZKBio Access IVS security platform, ensuring comprehensive security management. Additionally, the KF1200[IC] adheres to the ZKTeco Cyber Security Base Line (ZKCSBL), providing advanced protection for user data.

Key Features:

• Equipped with ZKTeco visible light facial recognition, one of the industry’s best technologies
• Supports up to 1,500 facial templates, 30,000 cards, and 100,000 records
• Multiple communication ports: TCP/IP, Wiegand output, RS485 (coming soon), and Wi-Fi (coming soon)
• User-friendly onboard web server for quick system configuration
• Fully compatible with inBio Series controllers and the ZKBio Access IVS security platform
• Compliant with ZKCSBL (ZKTeco Cyber Security Base Line) for advanced protection

IP-Based Biometric Door Access Control Panel

A high-performance access control panel for a single door, featuring built-in access control functions and support for RS485 fingerprint readers and Wiegand RFID readers. Communicates via TCP/IP and supports up to 20,000 fingerprint templates, 60,000 cards, and 100,000 transactions. Compatible with up to four readers.

Key Features:

• Versatile Reader Support – Works with FR Series fingerprint readers via RS485 and traditional RFID readers via Wiegand input.
• Beyond Door Control – Provides additional control with auxiliary relays for expanded functionality.
• Seamless Communication – Easily integrates into your network with HTTP/HTTPS support.
• High Capacity – Stores up to 20,000 fingerprint templates, 60,000 cards, and 100,000 transactions.
• Advanced Security Features – Includes Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and I/O linkages for enhanced security.
• Cost-Effective – Firmware upgrades can be performed without specialized tools, reducing maintenance costs.

The ZKTeco inBio-260 Pro is an IP-based biometric door access control panel designed to manage security for two doors. It supports up to eight readers, including four RS485 fingerprint readers and four 26-bit Wiegand readers, offering flexibility in reader integration. The system can store up to 20,000 fingerprint templates, 60,000 cardholders, and log 100,000 events and transactions, ensuring robust data management. Communication is facilitated through TCP/IP, allowing seamless integration into existing network infrastructures. Advanced access control features such as Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and auxiliary input/output linkages are built into the controller firmware, enhancing security measures.

The inBio-260 Pro is equipped with a 32-bit 1.2GHz CPU, 128MB RAM, and 256MB flash memory, ensuring efficient processing and storage capabilities. It operates within a power range of 9.6V-14.4V DC and functions optimally in temperatures between 0°C and 45°C, with an operating humidity of 20% to 80%. The controller’s firmware is upgradable without the need for advanced tools, ensuring the system remains current with the latest features and security enhancements. Additionally, the inBio-260 Pro offers more than just door control; it provides access to additional controls and interfaces with auxiliary relays, allowing integration with lights, alarms, and intrusion detection panels.

Key Features:

• Support different types of readers. The FR Series of readers transmit fingerprint templates to inBio Pro via RS485. Wiegand inputs are also provided for traditional RFID readers
• More than Door Control. Access additional control and interface with auxiliary relays
• Communication. Can be installed easily on your network and support both HTTP/HTTPS communication
• Capacity. Support up to 20000 fingerprint templates, 60,000 cards and store up to 100,000 events and transactions
• Advanced Access Control Built-In. Anti-Passback, First-Card Opening, Multi-Card Opening, Duress Password Entry, and Auxiliary input/output linkages are built into controller firmware
• Lowest Total Cost of Ownership. Controller firmware can be upgraded without any advanced tools
